HT SD Black Carbon fiber SPCTX160

HT SD Black Carbon fiber PPF Wrap – SPCTX160 CLS-TPUTC06 (SG)



Transform your vehicle with HT SD Black Carbon fiber, a high-performance colored  PPF that offers dazzling mirror-like pink tones and advanced surface protection. Get the sleek carbon fiber look without the high cost. This high-gloss TPU film is self-healing, hydrophobic, and UV-resistant—built to handle scratches, sun, and grime. Flexible and easy to install, it conforms perfectly to curves for a clean, professional finish inside or out.



Product Description

Upgrade your vehicle’s style and defense with HT SD Black Carbon fiber, a premium TPU paint protection film featuring a deep, high-gloss finish over a modern forged carbon pattern. Built for both performance and design, this film offers exceptional protection and a head-turning finish.

This premium carbon fiber TPU film offers a realistic, high-gloss Carbon fiber appearance without the added weight or cost of real carbon components. Made from durable, high-grade TPU, it provides excellent protection against rock chips, UV rays, chemicals, and environmental damage.Its self-healing technology allows minor scratches to disappear with heat, while the hydrophobic, stain-resistant topcoat repels water, dirt, and grime for easy maintenance.

Key Features

Feature	Description
Carbon Aesthetic	Modern, high-end look with the unique texture and depth of carbon — now in a crystal-clear gloss finish.
Self-Healing Topcoat	Minor scratches, swirl marks, and surface marring can “heal” under heat (sunlight, hot water, heat gun) to restore smoothness.
Hydrophobic / Water‑Repellent Surface	Repels water, dirt, grime, and contaminants—making cleaning easier and reducing stain buildup.
Anti‑Yellowing / UV Stability	Engineered to resist yellowing or discoloration over time, even under prolonged UV exposure.
High Impact / Chip Resistance	Acts as a sacrificial layer to absorb stone chips, abrasions, and road debris to protect the underlying paint.
Chemical / Stain Resistance	Resists damage from bird droppings, insect acids, road salts, and general environmental contaminates.
High Gloss / Smooth Surface (No “Orange Peel”)	Smooth, high-gloss finish without textural defects or “orange peel” appearance.
Good Conform-ability & Stretch	Allows wrapping around curves, edges, mirrors, seams with minimal distortion or lift.
Clean Removal	Can be removed cleanly without damaging the underlying paint (when removed properly) if needed.



Technical Specifications

·       Film Type / Base Material: Thermoplastic Polyurethane (TPU)

·       Total Thickness: ~ 7.0 mil to 10.0 mil

·       Topcoat / Self-Healing Layer: ~ 0.8–1.0 mil

·       Adhesive System: Pressure-sensitive, repositionable acrylic adhesive

·       Roll Size Dimensions: 1.52 M × 15 M

·       Operating Temperature Range: –40 °C to +120 °C

·       Elongation / Tensile Strength: 150 % elongation

·       Gloss Level: 90+

·       Color Stability: 5,000+ hours under accelerated UV test

·       Warranty Conditions: Covers yellowing, cracking, delamination (under normal use and installation)

·       Life Span: 5-8 years with proper care.

Benefits

·       Dual-purpose: Color + Protection — Unlike plain colored PPFs, HT SD Black Carbon fiber gives you a dramatic, color-change effect while maintaining full protective functionality.

·       Long-Term Durability — Designed to last many years without fading, peeling, or losing optical clarity.

·       Low Maintenance — The hydrophobic surface repels contaminants, making washes easier and reducing the risk of stains and etching.

·       Restores “New Car Feel” — The mirror-like crystal finish gives vehicles a refreshed, custom look without needing new paint.

·       Preserves Underlying Paint — Serves as a sacrificial shield; if needed, it can be removed cleanly, protecting the factory finish beneath.

·       Flexibility in Use — Suitable for cars, motorcycles, boats, accent panels, mirror covers, hoods, etc.

·       Professional-Grade Installation — Excellent conformability helps installers wrap complex curves, tight edges, and recesses with minimal issues.

Usage & Installation Notes

1.     Surface Preparation

o   Ensure surface is fully clean, free from wax, sealants, oils, overspray, or contaminants.

o   Use isopropyl alcohol (IPA) or a dedicated PPF prep solution on the substrate.

2.     Wet-Application Method

o   Use a slip solution (water + slip additive) for positioning.

o   Once properly placed, squeegee out the fluid and tent the edges.

3.     Heat / Annealing

o   Use heat (heat gun) to help with conforming over curves, corners, and to reduce stress.

o   Gradual heating helps with “healing” the topcoat surface.

4.     Edge Sealing

o   For long-term durability, edges should be tucked or sealed, especially in harsh environments (marine, high humidity).

5.     Curing Period

o   Allow adhesive to fully cure (24–48 hours) before exposing to extreme conditions or automated car washes.

6.     Cleaning / Maintenance

o   Use pH‑neutral, non-abrasive wash soaps.

o   Avoid harsh chemical cleaners, strong solvents, abrasive pads.

o   Periodic gentle polish or maintenance coat can help preserve gloss but should be mild and safe for PPF.

7.     Removal

o   When removal is needed, gently heat and peel slowly at a low angle; the film should come off cleanly if conditions were met.

Why Choose Our PPF Wraps?

• Premium-grade TPU film with long-lasting performance
• Easy to apply with excellent stretch & conformability
• Professional look with self-healing technology
• Protects against road debris, oxidation, and discoloration
• Backed by quality and performance you can trust
